Greenlee's 180XL Visual Fault Locator

by Julie Clark on January 13, 2015
greenleetextron

For fast and easy fault finding, choose the 180XL Visual Fault Locator. Greenlee Textron fiberTOOLS™ are EFFICIENT: quickly and easily locate high losses and faults in fiber optic cables; with EXTENDED REACH: up to 7km measurement range, and VERSATILE: with pulsed and CW mode of operations.


Ordering information:

180XL Visual Fault Locator
1.25mm Adapter 1.25mm Adapter for LC and MU connectors
greenlee180xl
Specifications:
Wavelength  650nm +/-10nm
Emitter Type  Fabry Perot
Output Power  0dBm
Laser Classification  Class 2
Range  7km
Modes of Operation  CW and 2Hz Modulation
Method of Display Operation  Red/Green LED
Fiber Type  Singlemode, Multimode

Battery

Battery Life

AA (2 included)

80 Hours with 3.9Wh Batteries

Weight

Dimensions

Operating Temperature

Storage Temperature

Certifications

0.26lbs, (120g) (not including batteries)

7.08” x 0.91” Dia (180mm x 23mm Dia)

-10ºC to +45ºC

-40ºC to +70ºC

CE, CDRH





Click here for full product specs and demo video.
