Hitachi's Power+™ Composite Indoor/Outdoor Cables

by Bobby Salerno on August 3, 2020

Composite Fiber Strands & Copper Conductors

Power+™ composite indoor/outdoor cables are the solution for applications where remote power and network connectivity are required and distance may be a factor. Power+™ composite cables utilize fiber optic strands to provide the link to the network and a pair of stranded copper conductors to deliver power. The different constructions of Power+™ composite cables address the variety of applications on the market. Power+™ composite cables are ideal for Distributed Antenna Systems (DAS), Passive Optical Networks (PONS), Small Cell applications, long distance CCTV applications and a wide range of IoT applications.

Designed for Long Distance Power over Ethernet (PoE) Applications

• Multimode and singlemode glass available (2, 6 & 12 strand)

• Two copper conductors per cable (choose from 12, 14, 16, 18, 20 & 22 gauges)

• Stranded copper conductors (7-19 strands) offer greater cable flexibility

• Supports 6.49 watts of power (IEEE 802.3af up to 10,000 feet)

• Supports 12.95 watts of power (IEEE 802.3af up to 5,100 feet)

• Supports 25.5 watts of power (IEEE 802.3at up to 2,700 feet)

Cable Design allows Easy Termination and Wide Use

• UL Listed OFCP for use in plenum spaces

• OSP rating permits use in outdoor and wet environments

• Small outside diameters assist in installation

• Tight buffered (900 micron) optical fibers reside inside individual aramid yarn filled subunits

• Compatible with all LC and SC fiber optic connectors

• Fiber optic glass options include OM1, OM2, OM3, OM4, OM5 & OS2

• Mitigates temperature rise associated with cable bundles
Screen Shot 2020-08-03 at 11.11.43 AM
