Planning for Next-Gen Wi-Fi 6E

On April 23rd, the FCC released 1,200MHz (1.2GHz) of spectrum for unlicensed use in the 6Ghz band, greatly extending the amount of bandwidth for Wi-Fi and other unlicensed technologies.

This epic release of spectrum, the largest in 20 years, accelerates the growth of IoT. Additional spectrum means less interference and lower latency, which will ultimately offer wireless networks higher performance and faster speeds. Wi-Fi has typically been operating in 600MHz bandwidth at 2.4GHz and 5GHz bands.

The added spectrum of 1.2GHz will provide a significant improvement in the performance of your Wi-Fi network once the Wi-Fi 6E devices are available. Devices are expected to be available at the end of this year; however, the Wi-Fi Alliance will offer certification programs for Wi-Fi 6E compliance in Q1 2021. With all the additional bandwidth, there’s potentially more flexibility for channel bonding and less interference. Today, 4G LTE mobile carriers encourage the offload to current Wi-Fi infrastructures, and we will undoubtedly experience 5G mobile offload to Wi-Fi 6E.

Consider the cabling infrastructure. Continuing to use Cat 5e and Cat 6 cabling will not be adequate for the support of next-generation high-speed Wi-Fi technologies. Best practice is the installation of two Cat 6a cables for each wireless access point for future technology requirements. For example, ANSI/BICSI 004-2018 Wireless Local Area Network WLAN) Systems Design and Implementation Best Practices states, “If balanced twisted-pair cabling is used, the cabling shall, at a minimum, meet Category 6A/Class EA performance.” Additionally, “two horizontal links are recommended for each AP.” Similarly, current TSB-162-A Telecommunications Cabling Guidelines for Wireless Access Points recommend Cat 6A/Class EA performance, adding to follow the performance testing outlined in the most current TIA-568.C. Other documents are subsequently recommending the same arrangement, two Cat 6a cables to each Wi-Fi access point.

Modernize your wireless physical installation methods to prepare for the future

The constant evolution of wireless technologies and the significant number of devices required to enable a robust infrastructure have clearly shifted the industry to require new and improved methods of installing wireless equipment. As technology evolves, It is clear that installation methods must evolve as well. Traditional methods have changed little over recent decades. There is undeniably a need to provide installation methods for seamless deployment and adequate functionality for the areas in which they serve. Designers, architects, contractors and building owners are seeking new ways to deploy wireless equipment in the ceiling space with critical operational support and aesthetics suitable to architecturally sensitive areas.

Selecting an Installation Method: Considerations

• Eliminate the need for holes and gaps in the ceiling tiles for cable egress.
• Simplify installation while concealing and protecting wireless equipment and cabling components without compromising performance of the wireless network.
• Provide full access to wireless equipment and associated cabling and components for maintenance and serviceability without the need to enter the ceiling space.
• Provide an installation that offers a built-in, easy migration path to future wireless access points. The need will arise when your current wireless equipment is exchanged for newer advanced equipment.
• Choose a lockable installation method for the prevention of tampering.
• Simplify hospital ICRA procedures with a ceiling installation method permitting access to the installed equipment without opening the above-ceiling space. Use a ceiling enclosure in the critical environments requiring a barrier between the work space and the above-ceiling space.
• Ceiling enclosures should be UL listed with a UL label stating “Ceiling Mounted ITC equipment,” acceptable in ALL jurisdictions.
• Consider an installation method with room to stow excess cable service loop and associated components while providing quick and easy access to all components.
• Select an installation method with better aesthetics, blending into the environment.
• Provide consistency in the look and function throughout the facility as well as ease of operational support.
